Discovering the question-critical moments: Towards building event-aware multi-modal large language models for complex video question answering

We thank the reviewer for the valuable feedback on our paper. In the next paragraphs, we address the comments provided by the reviewer.

Q1: Differences from previous approaches.

(1) We explore how to utilize a pre-trained MLLM for complex VideoQA tasks, instead of designing a new network from scratch.

As you mentioned in your review, there are many previous works [1,2,3,4] that tackle VideoQA with an attention mechanism. However, works in this line typically devise independent neural network models from scratch (e.g., similar to the relationships between Alexnet, Vggnet, and Resnet). Instead, our work is on the basis of a pre-trained MLLM, and our motivation is to enhance its video-language reasoning ability through our method.

(2) We utilize the attention mechanism for the hard selection of frame features, instead of the weighted summation of frame features.

As we concluded in the 2nd paragraph, Sec. 1, current methods utilizing MLLM for VideoQA simply concatenate the features of uniformly sampled frames, which is not sufficient for tasks featuring causal-temporal reasoning. In light of this, we extract frame features with temporal information (Sec. 3.1), select features of continuous frames that are crucial for answering the question (Sec. 3.2), and preserve the general context of the whole video (Sec. 3.3). It is particularly emphasized that the core of our method, the question-critical keyframes retriever (Sec. 3.2), selects frames in a hard way, which means we didn't change the spatial-temporal features $V _{ST} \in R^{T \times N _C \times D _C}$ where we extracted in Sec. 3.1, and we just select W features of continuous frames in $V _{ST} \in R^{T \times N _C \times D _C}$ as our question-critical spatial-temporal frame features $V _{Key} \in R^{W \times N _C \times D _C}$. For comparison, the attention mechanism in [1,2,3,4] is used in a soft way, which means they change the frame features they extracted by the weighted summation in attention mechanism.

(3) A detailed discussion of different strategies for frame selection.

Here, we compare the mechanism of frame selection in our method with the two latest works in complex VideoQA, including TranSTR [2] and MIST [3]. The core difference between our method and others is that we select continuous frames as the question-critical event, instead of discrete frames separately distributed across different timestamps within videos. For example, TranSTR [2] selects K frames according to the highest k scores in the cross-attention map between frame embeddings and question embeddings, with the perturbed maximum method [4]. MIST [3] selects K frames by simply conducting Gumbel-Softmax sampling K times. Both of them result in a selection of K discrete frames and would disrupt the intrinsic coherence between adjacent frames, which we think cannot constitute an event ("event" here means K continuous frames). Therefore, we use a 1D-Conv with a window size of K on the attention scores $M \in R^{T}$ to get an event level scores $\hat{M} \in R^{T-K+1}$ (illustrated in the 2nd paragraph of Sec. 3.2), followed with a Gumbel-Softmax and a matrix multiplication with the transformation matrix we defined in Equation (4). For more fair comparisons with the method using MLLM, we have added another experiment to verify the effectiveness of our proposed question-critical keyframes retriever based on the InstructBLIP-Vicuna-7B in the NExT-QA test set as shown in the following table,

References
[1] Jiyang Gao, Runzhou Ge, Kan Chen, and Ram Nevatia. Motion-appearance co-memory networks for video question answering. In CVPR, 2018
[2] Yicong Li, Junbin Xiao, Chun Feng, Xiang Wang, and Tat-Seng Chua. Discovering spatio-temporal rationales for video question answering. In ICCV, 2023
[3] Difei Gao, Luowei Zhou, Lei Ji, Linchao Zhu, Yi Yang, and Mike Zheng Shou. Mist: Multi-modal iterative spatial-temporal transformer for long-form video question answering. In CVPR, 2023.
[4] in Jiang and Yahong Han. Reasoning with heterogeneous graph alignment for video question answering. In AAAI, 2020
[5] Quentin Berthet, Mathieu Blondel, Olivier Teboul, Marco Cuturi, Jean-Philippe Vert, and Francis Bach. Learning with differentiable pertubed optimizers. NeurIPS, 2020

Dear authors.

I sincerely thank you for your fast response. I carefully read the whole, and I understand what the authors mentioned. However, I still don't think the shape of the current manuscript is the most effective way of delivering the main point of this work and could lead to misunderstanding on a few parts if someone did not check this thread.

First, regarding the attention-related part, the authors also agree that the attention mechanism and continuous frame selection is NOT a new approach. Prior works generally subsample every n frame (someone may say it is just a matter of changing fps unless it drops a large amount of information, e.g., 32 fps to 4 fps). However, most approaches presented before MLLM sell dynamic frame selection as more effective (with 3D conv, memory network, etc). This paper tries to show that such trends do not hold in MLLM, and I believe that is (one of) the core message of this paper. However, I think this flow is not well delivered to the current manuscript (and it is very easy to fall into misunderstanding).

Also, I did check the dimensions in the paper but failed to find the detailed equations from all in the current main manuscript. As those are the critical components, they need to be very clearly delivered in the manuscript (some people may be able to 'decode' based on the current response, but it is still challenging without this response; i.e., it is hard to say the readers can replicate this approach just with the manuscript. Plus, the texts in the figures as those are extremely small). It would be even better if the author could back-reference the exact equation of each matched part in the experiments (I still think Sections 1-3 and 4-5 need to be better connected).

In sum, I do think this work needs some significant revision (Sections 1-3, especially). As a reviewer who really believes it could be unfair to check multiple revisions within the review period (I do believe the author-rebuttal discussion period is mainly for resolving the misunderstandings, not for revisiting the writing multiple times), I will not add comments on the revised version. However, I will revisit the main manuscript or this thread (without any biases) during the reviewer discussion period (NOT during the author-reviewer discussion period) and revise my score based on the revision.

We greatly appreciate your constructive and insightful comments, and we address your major concerns below.

Weakness 1: A detailed comparison and analysis of works utilizing frame selection in VideoQA.

For method with MLLM.
As far as we know, SeViLA [1] is currently the only work that utilizes an MLLM for VideoQA. However, there are several main differences between SeViLA and our method. Firstly, SeViLA adopts a two-stage training, while our method is a differential selection with end-to-end training. SeViLA firstly per-train the model on the QVHighlights for 80 epochs and then finetune the model on downstream tasks. Instead, our method only needs to be fine-tuned once on downstream tasks thanks to the differentiability of our question-critical keyframes retriever. Secondly, SeViLA locates frames by prompting LLM, while we compute the attention map as the basis for our frame selection. We introduce the text encoder, which has been jointly pre-trained with the image encoder, to compute the attention map between spatial frame embeddings $E _S \in R^{T \times D _{I}}$, and question embeddings $E _Q \in R^{1 \times D _{I}}$. We then select the continuous W frames that are most crucial in a differentiable way. Thirdly, SeViLA extracts spatial frame features via the frozen ViT independently, while we extract frame features with temporal information. We add trainable adapters in the frozen ViT (Figure 3 (a)) so that we can build temporal relationships between frames during feature extraction (Sec 3.1).

For method without MLLM, and why we choose a 1d Conv.
As you mentioned in your reviews, there are some other works that present frame selection in VideoQA. Here, we compare the mechanism of frame selection in our method with the two latest works in complex VideoQA, including TranSTR [2] and MIST [3]. The core difference between our method and others is that we select continuous frames as the question-critical event, instead of discrete frames separately distributed across different timestamps within videos. For example, TranSTR [2] selects K frames according to the highest k scores in the cross-attention map between frame embeddings and question embeddings, with the perturbed maximum method [4]. MIST [3] selects K frames by simply conducting Gumbel-Softmax sampling K times. Both of them result in a selection of K discrete frames and would disrupt the intrinsic coherence between adjacent frames, which we think cannot constitute an event ("event" here means K continuous frames). Therefore, we use a 1D-Conv with a window size of K on the attention scores $M \in R^{T}$ to get an event level scores $\hat{M} \in R^{T-K+1}$ (illustrated in the 2nd paragraph of Sec. 3.2) followed with a Gumbel-Softmax and a matrix multiplication with the template matrix we defined in Equation (4). For more fair comparisons with the method using MLLM, we have added another experiment to verify the effectiveness of our proposed question-critical keyframes retriever based on the InstructBLIP-Vicuna-7B in the NExT-QA test set as shown in the following table,

Results comparison with SeViLA.
The results on Table 1 and 2 are from the model with Vicuna, while Table 3 shows that models with FLAN-T5 perform much better (74.5 on NExT-QA, surpassing the results of 73.8 in SeViLA). For a clear comparison with SeViLA, we reorganize the results of models with FLAN-T5:

References
[1] Shoubin Yu, Jaemin Cho, Prateek Yadav, and Mohit Bansal. Self-chained image-language model for video localization and question answering. arXiv preprint arXiv:2305.06988, 2023.
[2] Yicong Li, Junbin Xiao, Chun Feng, Xiang Wang, and Tat-Seng Chua. Discovering spatio-temporal rationales for video question answering. In ICCV, 2023
[3] Difei Gao, Luowei Zhou, Lei Ji, Linchao Zhu, Yi Yang, and Mike Zheng Shou. Mist: Multi-modal iterative spatial-temporal transformer for long-form video question answering. In CVPR, 2023.
[4] Quentin Berthet, Mathieu Blondel, Olivier Teboul, Marco Cuturi, Jean-Philippe Vert, and Francis Bach. Learning with differentiable pertubed optimizers. NeurIPS, 2020

Weakness 2: Performance gains seem to rely on the pre-trained MLLM.

Since our target is to improve video-language reasoning in complex VideoQA tasks on the basis of MLLM, and a powerful MLLM would be our first choice. Intuitively, a weaker MLLM will lead to a performance drop while we don't think there is a necessity for this evaluation. Instead of looking back, we believe more powerful MLLM in the future will empower our work better. Also, we would like to emphasize that the performance improvement mainly benefits from the E-STR method, composed of trainable adapters, a well-designed question-critical keyframes retriever, and a general context encoder, instead of a simple adaptation. Although our adapters and general context encoder are not as effective as the question-critical keyframes retriever, they can still promote video reasoning in complex VideoQA tasks ((w/o ST (-0.7)), (w/o GCE (-0.5)) in Table 5) which we think is necessary.

Weakness 3,4,5: More benchmarks, further qualitative results, and limitations:

More experiments on other benchmarks are in the SUPPLEMENTARY C of the original paper.

We applied our method to additional VideoQA tasks, including MSVD-QA, MSRVTT-QA, and ActivityNet-QA.

More qualitative results and further discussions about the limitations are in the SUPPLEMENTARY D of the original paper.

We selected more typical examples for both successive and failure analysis, along with the discussions about the limitations (Sec 4.4 and Supplementary D).

Question 1: "spatial frame features (--> embeddings)" and the "spatial-temporal frame features"

spatial frame embeddings

Thanks for your careful review of our paper, we first make a minor correction in your expression. In our paper, we use "spatial frame embeddings" to refer to the spatial frame features in your review. As we defined in the 2nd paragraph, Sec.3.1, the spatial frame embeddings $E _S \in R^{T \times N _I \times D _I}$ are extracted from a totally frozen image encoder without adapters (illustrated in the upper right of Figure 3 (a), since each frame is encoded independently without temporal information, we only use the term "spatial"), $N _I$ is the patch number of each frame (including the class token), and $D _I$ is the embedding dimension. We only keep the class tokens of $E _S \in R^{T \times N _I \times D _I}$, resulting in $E _S \in R^{T \times D _I}$.

spatial-temporal frame features

The main difference between the embeddings $\in R^{N _I \times D _I}$ and features $\in R^{N_C \times D _C}$ in our paper is that, features refers to embeddings through the Qformer (features $\in R^{N_C \times D _{C}}$ = Qformer (embeddings $\in R^{N _I \times D _{I}}$)), and this is why the dimensions of "spatial frame embeddings" $D _I$ and "spatial-temporal frame features" $D _C$ not consistent. Similarly, we get the spatial-temporal embeddings $E _{ST} \in R^{T \times N _I \times D _I}$ by feeding frames into the image encoder with adapters (the adapters learn to build the relationships between frames, so we use the term "spatial-temporal"). We then feed $E _{ST} \in R^{T \times N _I \times D _I}$ into the Qformer to get the "spatial-temporal features" $V _{ST} \in R^{T \times N _C \times D _C}$ (defined in the 2nd paragraph, Sec.3.1).

The differences between $E _S \in R^{T \times D _I}$ and $V _{ST} \in R^{T \times N _C \times D _C}$ and why we remain $E _S \in R^{T \times D _I}$

Since $E _S \in R^{T \times D _I}$ are extracted from the completely frozen image encoder in EVA-CLIP, they are naturally aligned with the question embeddings $E _Q \in R^{D _I}$ which we extracted with the frozen text encoder in EVA-CLIP (also supported by the ablation results in Table 6). The $E _S$ and $E _Q$ are only responsible for computing the attention map $M \in R^{T}$, which will be used to select the continuous W frame features in $V _{ST} \in R^{T \times N _C \times D _C}$, resulting in the $V _{Key} \in R^{W \times N _C \times D _C}$ (as illustrated in Sec. 3.2).

Question 2: About the ST-Adapter [1]

The original ST-Adapter is only a 3D-Conv kernel before the MHSA layer in the transformer block (Figure 3 (a)), we additionally introduce a parallel MLP-based Adapter to refine the frozen parameters in the MHSA and FFN layers to align better with the ST-Adapter. The ablation results in Table 8 validate this.

[1] Junting Pan, Ziyi Lin, Xiatian Zhu, Jing Shao, and Hongsheng Li. St-adapter: Parameter-efficient image-to-video transfer learning. In NeurIPS, 2022.

Weakness 3: Experiments are not fair.

From your constructive reviews, we think the "two-stage" means an additional involvement in the process of frame selection. In our main results of Table 1 and Table 2, the methods of MIST and TranSTR all involve a process of frame selection as we talked about above. Based on your valuable comment, for more fair comparisons with the method using MLLM, we have added another experiment to verify the effectiveness of our proposed question-critical keyframes retriever based on the InstructBLIP-Vicuna-7B in the NExT-QA test set as shown in the following table,

Weakness 4: Efficiency comparison.

During inference, the only added parameters are all lightweight. For example, the parameters of our adapters, question-critical keyframes retriever, and general context encoder are 28M, 2M, and 9M respectively. Since the majority of computation costs of the MLLM come from the LLM, we can achieve a fair computation efficiency as well as reduce the tokens directly fed into the LLM, that's also what our methods do as we mentioned in Sec. 4. Computation efficiency.. In Table 4, our method achieves a GFlops of 9673, which is close the to GFlops of 9382 of concat-6, because we only feed 6x32 visual tokens into the LLM (the same as concat-6). Instead, concat-32 has a GFlops of 15616 because it feeds 32x32 visual tokens into the LLM. We display more results of the computation of efficiency below:

We compare more latency time and GFlops with different batch sizes during inference, along with the GPU memory and throughput with a batch size = 16, on a single NVIDIA A100 GPU. We still utilize NExT-QA and InstructBLIP-Vicuna 7B for this part. The results that are summarized above show that our model performs slightly slower than Concat-6 only, indicating that just a small overhead is introduced in inference speed by the adapters and additional modules in E-STR.

We greatly appreciate your constructive and insightful comments. Please allow us to restate the novelty of our work and the differences from other works.

Weakness 1 and 2: limited novelty and differences from other works

Different from the annotations in the datasets of Temporal Grounding, which explicitly annotate the timestamps for which segments in videos correspond to which query, the annotations in VideoQA only involve the tuple of $<question, answer, video>$. In light of this, we can only learn to seek the question-critical moment in VideoQA without explicit supervision, and the methods in the task of Temporal Grounding are not suitable here (e.g., the boundary regression loss $L _{reg}$ in [1] and the moment localization loss $L _{moment}$ in [2] are not applicable here). Therefore, the newly introduced technical designs lie in the question-critical keyframes retriever in Sec. 3,2. For further explanation, we compare the mechanism of frame selection in our method with the two latest works in complex VideoQA, including TranSTR [3] and MIST [4].

(1) We select continuous frames as the question-critical event, instead of discrete frames separately distributed across different timestamps within videos. TranSTR [3] selects K frames according to the highest k scores in the cross-attention map between frame embeddings and question embeddings, with the perturbed maximum method [5]. MIST [4] selects K frames by simply conducting Gumbel-Softmax sampling K times. Both of them result in a selection of K discrete frames and would disrupt the intrinsic coherence between adjacent frames, which we think cannot constitute an event ("event" here means K continuous frames). Therefore, we use a 1D-Conv with a window size of K on the attention scores $M \in R^{T}$ to get an event level scores $\hat{M} \in R^{T-K+1}$ (illustrated in the 2nd paragraph of Sec. 3.2) followed with a Gumbel-Softmax and a matrix multiplication with the template matrix we defined in Equation (4). Further, we fully utilize both the text encoder and the image encoder in CLIP. TranSTR encodes the questions with DeBERTa, and MIST encodes the questions with BERT. However, as the studies shown in Table 6, only the text encoder which has undergone large-scale contrastive learning with the image encoder can yield the highest performance since their shared understanding of the visual and textual content.

(2) We introduce learnable adapters to learn the temporal relationships between frames better As illustrated in Sec. 3.1, the vanilla ViT in CLIP cannot capture the temporal relationships and we introduce a 3D-Conv-based ST-Adapter [6] together with a parallel MLP-based adapter (in Figure 3 (a)) to make the process of feature extraction temporal aware. Instead, TranSTR and MIST extract the features of each frame independently, resulting in a lack of temporal relationships between frames. Our ablation studies in Table 5 (w/o ST (-0.7)) and Table 8 support the effectiveness of our method.

References
[1] Yulin Pan and Xiangteng He and Biao Gong and Yiliang Lv and Yujun Shen and Yuxin Peng and Deli Zhao. Scanning Only Once: An End-to-end Framework for Fast Temporal Grounding in Long Videos. In ICCV, 2023.
[2] Jie Lei, Tamara L Berg, and Mohit Bansal. Qvhighlights: Detecting moments and highlights in videos via natural language queries. In NeurIPS, 2021.
[3] Yicong Li, Junbin Xiao, Chun Feng, Xiang Wang, and Tat-Seng Chua. Discovering spatio-temporal rationales for video question answering. In ICCV, 2023
[4] Difei Gao, Luowei Zhou, Lei Ji, Linchao Zhu, Yi Yang, and Mike Zheng Shou. Mist: Multi-modal iterative spatial-temporal transformer for long-form video question answering. In CVPR, 2023.
[5] Quentin Berthet, Mathieu Blondel, Olivier Teboul, Marco Cuturi, Jean-Philippe Vert, and Francis Bach. Learning with differentiable pertubed optimizers. NeurIPS, 2020
[6] Junting Pan, Ziyi Lin, Xiatian Zhu, Jing Shao, and Hongsheng Li. St-adapter: Parameter-efficient image-to-video transfer learning. In NeurIPS, 2022.

We sincerely thank you for the constructive comments. We address your major concerns below.

The relationships between the results and our motivation.
The majority of our motivation is two folds: (1) build temporal relationships between frames which will be input to the frozen ViT in EVA-CLIP. (2) Retrieve keyframes that are crucial to answer the given question.
For motivation (1), we insert the 3D-Conv based ST-Adapter [1] into the frozen ViT in EVA-CLIP, according the conclusion in paper [1] demonstrated that “ST-Adapter is capable of extracting and leveraging the pre-trained knowledge of a large image model to achieve superior video understanding at a small parameter cost.”, which is also consistent with our ablation experimental results in Table 5 (w/o ST (-0.7)) and Table 8.
For motivation (2), in addition to the ablation studies in Table 5 (w/o QKR (-2.1)) which suggest the necessity of our question-critical keyframes retriever, we also show more qualitative results in Figure 7 to visualize the retrieved frames. We can observe that the retrieved frames are evidently relevant to the given questions. Although we admit that it’s hard to present a quantitative analysis (in addition to performance improvements in Table 1 and 2) to figure out whether our retriever truly discovers the question-critical moments, we additionally add another experiment to validate this.
Specifically, we transform the annotations of questions and answers in the test set of NExT-QA into a declarative sentence (e.g., [“what is the girl doing with the bottle?”, “feeding the doll”] --> “The girl is feeding the doll”), and we use the CLIP (ViT-large-224) to compute the similarities between the declarative ground-truth and the sampled 32 frames in videos. Here, we approximate the frame with the highest similarity as the most important among all 32 frames and determine the rate whether the frame with the highest score is among the 6 frames we have retrieved.

From the results, we can find that our method has a rate of 77.1% to include the frame with the highest score. For comparison, the uniformly sampled frames only have a rate of 19.6%. We believe that these conclusions can reflect the relationships between our experimental results and our motivation.

The realization of “event-aware."
Here, we define the event as W continuous frames (W=5 here) and the core of our idea is to seek the continuous W frames that are most crucial among the sampled T frames (T=32 here). Figure 3 (c) demonstrates our question-critical keyframes retriever, the most important component in our framework. Briefly, given the T frame embeddings $E _S \in R^{T \times D _{I}}$, and question embeddings $E _Q \in R^{1 \times D _{I}}$, our retriever can locate the continuous W frames that are most crucial for the question according to the similarities $M \in R^{T}$ between $E _S$ and $E _Q$, and we will use the spatial-temporal features of retrieved frames for further reasoning, resulting in the term of “event-aware”.

Results in of concat-32 in Table 4.
The baseline results in Table 1 and 2 are the results from InstructBLIP (Vicuna-13B), and the results in Table 4 come from InstructBLIP (Vicuna-7B) as we have mentioned in Sec. 4.2. “Comparison with State-of-the-arts.” that all our further experiments are conducted with InstructBLIP (Vicuna-7B). Therefore, the results of concat-6 in Table 4 are consistent with the results of Vicuna-7B in Table 3 (68.4).
The baseline of concat-32 in Table 4 is a concatenation of all sampled 32 frames without selection, and it’s natural that its performance is better than concat-6, 12, 24 since it involves more video information. However, this result comes at the cost of an extreme length of visual tokens (32×32) and greater computational complexity (15616 GFLOPs). Instead, our method only concatenates visual tokens of 5 selected frames along with a context representation, resulting in a smaller number of visual tokens ((5+1)x32, 5 is the selected frames, 1 is the general context), which is equal to the number of visual tokens in concat-6 (6x32, meaning the same capacity of visual information directly fed into the language model as our method) and that’s the reason why we choose the models with a concatenation of 6 uniformly sampled frames as our standard baselines in Table 1 and 2. Notably, despite concat-32 (32x32 tokens, 15616 GFLOPs) in Table 4 achieving an accuracy of 71.1, it still lags behind our method (71.7, with only 6x32 tokens and 9673 GFLOPs), emphasizing the effectiveness of our E-STR.

References [1] Junting Pan, Ziyi Lin, Xiatian Zhu, Jing Shao, and Hongsheng Li. St-adapter: Parameter-efficient image-to-video transfer learning. In NeurIPS, 2022.
